Everything You Should Know About 36V eBike Battery Range, Build, and Real-World Tips

Riding electric bike with custom ebike battery at 36 volts is common, especially for commuters, city riders, and those who want a balance between cost, weight, and performance. From what I’ve read and from builds I’ve helped with, here’s a deeper dive into what 36V means, what to expect, and how to do it better (warts and all).

1. What “36V” really means

“36V” is the nominal voltage of the pack — in practice, fully charged it might be around 42V, and when discharged it should drop to something like 30V before the battery management system (BMS) cuts off to avoid damage.

That means, although you see “36V”, the usable range of voltage is wider. Controllers need to be compatible with this range, or you’ll get voltage sag, poor performance, or even risk damage.

2. How capacity & voltage combine to affect range

One formula that keeps showing up is:

Wh = Volts × Amp-Hours (Ah)

So 36V × 13Ah battery has ~468 Wh.

What that translates into, for real riding, depends heavily on a lot of variables:

• Rider weight
• Terrain (hills vs flat)
• How much you pedal vs relying on throttle or assist
• Speed, wind resistance, tire pressure

From experiences people share: a 36V pack with around 10-14 Ah often gives 30-60 km (≈ 20-40 miles) in mixed riding conditions.

If you bump up capacity (say 15-20 Ah), the range goes up, but so does weight, cost, and size. At some point you’re carrying more battery than you need. My own test ride with 11Ah on a 36V saw promising numbers until I hit hills or harsh wind — then performance dropped more than I expected.

3. Advantages & trade-offs of 36V vs higher voltages

Using a 36V battery (versus, say, 48V) has pros and cons. Here’s what I gathered + what I found from building or helping others build:

4. How to choose or build a good 36V custom ebike battery

Since custom ebike battery is the core, here are concrete steps + my own lessons:

a) Decide your target usage

• How far you ride daily (commute, errands, weekend ride)
• Terrain: flat vs hills, stop & go vs steady speed
• Weight you carry (bike + rider + load)
• Weather: heat, cold — batteries suffer both ends

Knowing these helps pick Ah, battery shape, cooling, mounting, etc.

b) Capacity & cell selection

• Choose Ah that matches your range goal, but don’t overshoot too much (you’ll carry extra weight)
• Cell chemistry matters: some offer energy density, others offer better stability / longer life. My builds with higher energy-density cells gave more miles but heated up more; had to add cooling or good ventilation.
• BMS: must support the current your motor draws and offer safety features (over-discharge, overcharge, cell balancing). Better to over-rate BMS rather than under. I once used a BMS that was just barely rated; under hard load it got hot and dropped output. Changing to a beefier BMS made it more stable.

c) Construction & packaging

• Layout: series (to reach voltage) × parallel (to get current + capacity) cell arrangement must match space. If your frame has limited space, shape the pack to fit (slim, flat, external rack etc.).
• Wiring & connections: use thick wires, good connectors; minimize resistance and potential weak spots. Spot welding or well-done nickel strip connections is preferred. Keep things clean, well insulated.
• Enclosure: good casing that protects from water, vibration, and has some airflow or heat paths. Even if not perfect, sealing critical joints helps. My first custom battery pack got damp inside — performance dropped until I fixed the seal.

d) Charging, care & safety

• Use correct charger that matches voltage and chemistry. Don’t overcharge. For a “36V” pack, charger should match its full charge voltage.
• Storage: if not using for a while, store at partial charge (around 40-60%), in a cool, dry place.
• Regular checks: look for swelling, loose wires, heat spots. Clean contacts. Keep battery case clean.
• Real-world testing: don’t trust only spec-sheet. Do a full charge/discharge test in conditions similar to your usual riding. Measure real range & temperature behavior.

5. What to expect in real rides (my experiments + others)

• On flat or gently rolling terrain, using pedal assist, a 36V 10–12Ah pack often gives 25-45 km with good setup. If you go full throttle or steep hills, that drops a lot.
• If battery is under-spec’d in Ah relative to motor draw, you’ll see voltage sag: slower take-offs, less power on hills.
• Temperature affects a lot: hot weather reduces life or increases sag; cold weather also cuts capacity. On a cooler morning, I lost ~10-15% range compared to midday rides.
• Charging habits matter: letting battery run down completely often, or always charging to 100% every time, can degrade life sooner. Using middle range (say 20-80%) can help longevity.

Conclusion

A 36V custom ebike battery is a solid choice for many riders: commuters, casual users, city dwellers. It offers a good balance of cost, weight, ease of maintenance, and performance—provided you choose your capacity, components, and build style carefully. If you plan for your real usage (terrain, load, assist level), and give attention to safety and enclosure, you’ll likely get a battery that rides well and lasts long.
